Personal Portfolio (Placeholder)

The Next.js + Tailwind build powering this site.

Implementation notes for the portfolio you're browsing — design system, content pipeline, animation layer, and MDX authoring workflow.

Next.jsReactDesign Systems
Personal Portfolio (Placeholder)

Quick Stats

Role: Designer & Developer
Duration: Ongoing
Next.js 16 (App Router)React 19Tailwind CSS v4MDX + Zod

Links

Site Repository

Personal Portfolio

You're reading this on the site it describes. The write-up covers the design decisions, tech choices, and content pipeline that power what you're seeing right now.

My previous portfolio was a rigid single-page build that made adding experiments painful. This iteration puts extensibility first: every piece of content lives in an MDX file, every component inherits from a shared design system, and the whole thing generates statically at build time.

Design system

The site is dark-only, built on the Rose Pine palette. Committing to a single mode eliminates the conditional branching that makes theming tedious and lets the colour choices be deliberately atmospheric rather than merely accessible.

Design system colour tokens
Tailwind v4 @theme inline block — all Rose Pine tokens as CSS custom properties.

Colour palette

TokenHexRole
love#eb6f92Primary accent, headings
gold#f6c177Secondary accent, CTAs
pine#31748fTertiary accent, links
foam#9ccfd8Highlights
iris#c4a7e7Decorative
surface#1f1d2eCard backgrounds
overlay#26233aLayered elements

Typography

Three fonts, three roles:

  1. Space Grotesk — display headings, brand mark.
  2. Readex Pro — body text, paragraphs.
  3. Roboto Mono — code, ASCII art, monospace contexts.

All loaded via next/font/google with variable mode for font-family CSS custom property injection.

Stack

  • App shell: Next.js 16 App Router with React Server Components, streaming layouts, and generateMetadata helpers per route.
  • Design: Tailwind CSS v4 + shadcn-inspired UI primitives, gradient overlays, and canvas background layers (animated gears, matrix rain).
  • Content: MDX files in content/projects and content/extras, validated with Zod at load time and rendered via next-mdx-remote.
  • Media: Raw assets → Sharp WebP pipeline → assets.json manifests — images reference manifest entries, missing files fall back to a gear placeholder.
  • SEO: Structured data (JSON-LD), dynamic OG images (Edge runtime, @vercel/og), sitemap, and RSS feed.

Content pipeline


The Zod schema is the single source of truth for what frontmatter is valid. Missing required fields throw at startup — no silent failures rendering half-empty pages.

MDX component map

Every MDX file has access to the full set of custom components:

  • <Image> / <Gallery> — responsive media with blur placeholders.
  • <Video> / <AudioPlayer> — hosted asset embeds with consistent framing.
  • <Embed> — YouTube and arbitrary iframe embeds.
  • <LinkButton> — gradient CTAs to repos, demos, or contact.
  • <RelatedContent> — cross-links to other entries by slug and type.
  • <Callout>, <Quote>, <Code>, <Markdown> — narrative building blocks.

Animation layer

The site uses three distinct animation systems:

  1. Framer Motion — entry animations (fadeUp), carousel transitions, staggered card reveals.
  2. CSS keyframes — pulse-glow on CTA buttons, the ambient body::after radial gradients.
  3. Canvas / rAF — matrix rain effect (c-matrix-layer.tsx), gear rotation overlay (gear-layer.tsx), skills marquee.
Hero reveal, featured carousel autoplay, and skills marquee — all at 60 fps.

The canvas layers sit at z-0 behind a z-10 content wrapper, keeping decoration fully separate from interactive elements.

OG image generation

Each project and extra gets a dynamic OG image generated at the Edge:

/api/og/projects/[slug]  →  800×400 branded card
/api/og                  →  default fallback
The ambient background tone I listen to while building thisListen
Your browser does not support the audio element.

Deployment

The site deploys to Vercel. Static generation means the hosting bill is essentially zero — Edge functions only fire for OG image requests.

A portfolio is never finished. It's a living record of who you are right now, and an invitation to become someone different.
